PartNo.: 20593-RW
Description: 90°METRIC FEMALE 24°CONE O-RING H.T. Interlock Non-Skive
Convertible code:
Material:Carbon Steel 45#
SurfaceTreatment:Zinc,Cr3+Plating,Clear White
Corrossion Resistent Hour:120h or longer
Degree: 90°
| PART NO. | THREAD T | HOSE BORE | TUBE O.D. | DIMENSIONS | ||||
| DN | DASH | A | B | E | W | |||
| 20593-30- 12RW | M30x2 | 20 | -12 | 20 | 101 | 53 | 57 | 36 |
| 20593-36- 12RW | M36x2 | 20 | -12 | 25 | 101 | 52 | 59 | 46 |
| 20593-42- 16RW | M42x2 | 25 | -16 | 30 | 122 | 75 | 73 | 50 |
| 20593-52-20RW | M52x2 | 32 | -20 | 38 | 151 | 87 | 78 | 60 |
This flange features a 90° metric female thread and a 24° cone angle, providing a robust and leak-free seal.
The inclusion of an O-ring creates an additional layer of sealing, further enhancing the flange's ability to withstand high pressures and prevent leaks. The O-ring also acts as a vibration damper, reducing the risk of connection failures due to vibrations or shocks.
The Interlock Non-Skive design of this flange simplifies installation by eliminating the need for skiving or cutting the hose. This not only saves time but also reduces the risk of damaging the hose during installation. The flange's ability to securely lock with the hose ensures a stable and long-lasting connection.
Manufactured from high-quality materials, the 90° Metric Female 24° Cone O-Ring H.T. Interlock Non-Skive flange is built to withstand the rigors of industrial use. Its durability and corrosion resistance make it suitable for use in harsh environments and demanding conditions.
Whether you're working in the automotive, oil and gas, or any other industrial sector, this flange offers a reliable and efficient solution for your high-pressure fluid or gas handling needs. Its precision engineering and robust construction ensure superior performance and long-lasting durability.
