Ferrules are commonly used in hydraulic systems as a means of attaching hoses and tubes to other hydraulic components.
Secure Connection: Ferrules use crimping or swaging techniques to create a secure attachment between the hose or tube and the other hydraulic component. This secure connection helps prevent fluid leakage and ensures system integrity.
Versatility: Ferrules are compatible with a wide range of hydraulic hoses and tubes, making them a versatile solution for many different hydraulic applications.
Precision Design: Ferrules are typically designed with precision to ensure a snug fit between the hose or tube and the other hydraulic component. This optimal fit helps maximize performance and minimize the risk of system failure.
Durability: Ferrules are typically made from high-quality materials such as stainless steel or brass, which provide excellent durability and resistance to wear and tear.
Easy Assembly: Ferrules are easy to assemble, requiring only basic tools and knowledge of the assembly process.
Overall, ferrules offer a unique combination of secure connection, versatility, precision design, durability, and ease of assembly, making them an essential component in many hydraulic system applications.
Part No.: 00110-A
Description: FERRULE FOR SAE100R1AT/EN 8531SN HOSE
Convertible code:
Material: Carbon Steel 20#
Surface Treatment: Zinc, Cr3+ Plating, Clear White
Corrossion Resistent Hour: 120h or longer
Degree: Straight
| PART NO. | HOSE BORE | DIMENSIONS | |
| DN | DASH | L | |
| 00110-03A | 5 | 03 | 23 |
| 00110-04A | 6 | 04 | 30.5 |
| 00110-05A | 8 | 05 | 30 |
| 00110-06A | 10 | 06 | 32 |
| 00110-08A | 12 | 08 | 34 |
| 00110-10A | 16 | 10 | 37 |
| 00110-12A | 20 | 12 | 42 |
| 00110-16A | 25 | 16 | 51 |
Ferrule SAE 100R1AT/EN853 1SN is a hydraulic hose standard that combines the specifications of the Society of Automotive Engineers (SAE) and the European Norm (EN). This hose type is commonly used in hydraulic systems where high pressure and durability are essential.
The SAE 100R1AT designation indicates that the hose has one layer of steel wire braid reinforcement, providing excellent resistance to high pressure and pulse. Meanwhile, the EN853 1SN standard ensures that the hose meets specific European quality and safety requirements.
This hydraulic hose is typically constructed with an inner tube made of oil-resistant synthetic rubber, a single layer of high-tensile steel wire braid for reinforcement, and an outer cover that is resistant to oil, weather, and abrasion.
SAE 100R1AT/EN853 1SN hoses are designed to transmit petroleum-based or water-based hydraulic fluids under high pressure, making them suitable for a wide range of applications in various industries such as construction, agriculture, mining, and more.
These hoses are known for their flexibility, durability, and ability to withstand high working pressures, making them a reliable choice for demanding hydraulic systems. When purchasing SAE 100R1AT/EN853 1SN hoses, it is essential to choose a trusted manufacturer to ensure quality and performance.
