Part No.: 4F
Description: ORFS MALE O-RING PLUG
Convertible code:
Material: Carbon Steel 45#
Surface Treatment: Zinc, Cr3+ Plating, Clear White
Corrossion Resistent Hour: 120h or longer
| PART NO. | THREAD | O-RING | DIMENSIONS | ||
| E | E | A | L | S1 | |
| 4F-04 | 9/16"×18 | 11 | 9.8 | 16.8 | 17 |
| 4F-06 | 11/16"×16 | 12 | 11.2 | 19.2 | 19 |
| 4F-08 | 13/16"×16 | 14 | 12.8 | 21.8 | 22 |
| 4F-10 | 1"×14 | 16 | 15.5 | 25.9 | 27 |
| 4F-12 | 1.3/16"×12 | 18 | 17 | 27.4 | 32 |
| 4F-16 | 1.7/16"×12 | 21 | 17.5 | 27.9 | 38 |
| 4F-20 | 1.11/16"×12 | 25 | 17.5 | 27.9 | 46 |
| 4F-24 | 2"×12 | 29 | 17.5 | 27.9 | 55 |
ORFS Male O-Ring Plug Introduction
The ORFS Male O-Ring Plug is a hydraulic fitting that features a male threaded end with an O-ring seal, designed for use in high-pressure fluid systems. This plug provides a leak-proof connection, thanks to the O-ring seal that ensures a tight and secure fit when mated with a compatible female port or adapter.
Constructed from durable materials, the ORFS Male O-Ring Plug offers excellent corrosion resistance and long-lasting performance, even in demanding industrial environments. The male threads allow for easy installation and removal, facilitating efficient maintenance and repairs.
This plug is widely used in various hydraulic applications, including automotive, aerospace, and industrial machinery, where reliable and leak-free connections are crucial. The ORFS Male O-Ring Plug's design ensures optimal performance and safety, making it a trusted choice for professionals in the field.
Whether you're working on a large-scale industrial project or a smaller-scale repair job, the ORFS Male O-Ring Plug offers a secure and dependable connection solution for your hydraulic system needs.
