Part No.: SAE 100 R16
Description: SAE 100 R16 Wire Braid Hose
Convertible code:
Inner Tube: Oil Resistant Synthetic Rubber
Reinforcement: One or Two Single Wire Braid Reinforcement
Cover: Oil And Weather Resistant Synthetic
Temperature Range: -40℃～+100℃
| HOSE | DN | HOSE SIZE | HOSE I .D . | HOSE O.D . | MAX W.P. | BURST | MIN.BEND RADIUS | |
| PRESSURE | ||||||||
| PART NO. | mm | DASH | inch | mm | mm | MPa | MPa | mm |
| R16-04 | 6 | -4 | 1/4" | 6.3 | 13 | 35 | 140 | 50 |
| R16-05 | 8 | -5 | 5/16" | 7.9 | 15 | 29.7 | 119 | 55 |
| R16-06 | 10 | -6 | 3/8" | 9.5 | 17 | 28 | 112 | 65 |
| R16-08 | 12 | -8 | 1/2" | 12.7 | 20 | 24.5 | 98 | 90 |
| R16-10 | 16 | -10 | 5/8" | 15.9 | 24 | 19.2 | 77 | 100 |
| R16-12 | 20 | -12 | 3/4" | 19.1 | 28 | 15.7 | 63 | 120 |
| R16-16 | 25 | -16 | 1" | 25.4 | 36 | 14 | 56 | 150 |
| R16-20 | 32 | -20 | 1.1/4" | 31.8 | 43 | 11.3 | 45.5 | 210 |
This hose stands out for its exceptional strength, durability, and flexibility, making it a trusted choice for professionals who require a reliable and high-performing hose solution.
At the heart of the SAE 100 R16 hose lies its wire braid reinforcement. This reinforcement structure, composed of high-tensile steel wires, offers superior strength and pressure resistance, ensuring safe and efficient fluid transfer even under extreme conditions. The wire braid also provides excellent kink resistance, preserving the hose's shape and integrity over time.
The inner tube of the SAE 100 R16 hose is crafted from synthetic rubber, which is highly resistant to oil and other hydraulic fluids. This material ensures long-lasting performance and maintains the hose's flexibility, allowing it to conform to various routing paths and installation configurations.
The outer cover of the hose is made from abrasion-resistant and weather-proof materials. This durable outer layer effectively guards against external damage, such as cuts and abrasions, ensuring the hose's longevity and reliability.
The SAE 100 R16 Wire Braid Hose is suitable for use in a wide range of hydraulic systems, including those found in heavy machinery, construction equipment, and automotive applications. Whether it's used for high-pressure fluid transfer or for critical hydraulic circuits, this hose delivers consistent and dependable performance.
In summary, the SAE 100 R16 Wire Braid Hose is a robust and high-performing hydraulic hose that offers exceptional strength, durability, and flexibility. Its wire braid reinforcement and oil-resistant inner tube make it suitable for handling various hydraulic fluids under high pressure, while its abrasion-resistant outer cover ensures long-term reliability.
