Part No.: 6405
Description: SAE/ORB Male x NPTF Female
Convertible code:
Material:Carbon Steel 45#
Surface Treatment:Zinc,Cr3+Plating,Clear White
Corrossion Resistent Hour: 120h or longer
Degree:Straight
| PART NO. | TUBE O.D | THREAD | LGTH | HEX | |
| B | A NPTF | L | H | ||
| 6405-02-02-O | 1/8 | 5/16-24 | 1/8-27 | 0.948 | 9/16 |
| 6405-02-04-O | 1/8 | 5/16-24 | 1/4-18 | 1.230 | 3/4 |
| 6405-03-02-O | 3/16 | 3/8-24 | 1/8-27 | 0.948 | 9/19 |
| 6405-03-04-O | 3/16 | 3/8-24 | 1/4-18 | 1.200 | 3/4 |
| 6405-04-02-O | 1/4 | 7/16-20 | 1/8-27 | 1.000 | 9/16 |
| 6405-04-04-O | 1/4 | 7/16-20 | 1/4-18 | 1.200 | 3/4 |
| 6405-04-06-O | 1/4 | 7/16-20 | 3/8-18 | 1.350 | 7/8 |
| 6405-05-02-O | 5/16 | 1/2-20 | 1/8-27 | 1.000 | 9/16 |
| 6405-05-04-O | 5/16 | 1/2-20 | 1/4-18 | 1.150 | 3/4 |
| 6405-05-06-O | 5/16 | 1/2-20 | 3/8-18 | 1.300 | 7/8 |
| 6405-06-02-O | 3/8 | 9/16-18 | 1/8-27 | 1.020 | 11/16 |
| 6405-06-04-O | 3/8 | 9/16-18 | 1/4-18 | 1.230 | 3/4 |
| 6405-06-06-O | 3/8 | 9/16-18 | 3/8-18 | 1.331 | 7/8 |
| 6405-06-08-O | 3/8 | 9/16-18 | 1/2-14 | 1.500 | 1-1/8 |
| 6405-08-02-O | 1/2 | 3/4-16 | 1/8-27 | 0.8 | 7/8 |
| 6405-08-04-O | 1/2 | 3/4-16 | 1/4-18 | 1.280 | 7/8 |
| 6405-08-06-O | 1/2 | 3/4-16 | 3/8-18 | 1.280 | 7/8 |
| 6405-08-08-O | 1/2 | 3/4-16 | 1/2-14 | 1.570 | 1-1/8 |
| 6405-08- 12-O | 1/2 | 3/4-16 | 3/4-14 | 1.760 | 1-3/8 |
| 6405- 10-04-O | 5/8 | 7/8-14 | 1/4-18 | 1.340 | 1 |
| 6405- 10-06-O | 5/8 | 7/8-14 | 3/8-18 | 1.400 | 1 |
| 6405- 10-08-O | 5/8 | 7/8-14 | 1/2-14 | 1.550 | 1-1/8 |
| 6405- 10- 12-O | 5/8 | 7/8-14 | 3/4-14 | 1.710 | 1-3/8 |
| 6405- 12-04-O | 3/4 | 1-1/16-12 | 1/4-18 | 1.490 | 1-1/4 |
| 6405- 12-06-O | 3/4 | 1-1/16-12 | 3/8-18 | 1.490 | 1-1/4 |
| 6405- 12-08-O | 3/4 | 1-1/16-12 | 1/2-14 | 1.720 | 1-1/4 |
| 6405- 12- 12-O | 3/4 | 1-1/16-12 | 3/4-14 | 1.790 | 1-3/8 |
| 6405- 12- 16-O | 3/4 | 1-1/16-12 | 1-11-1/2 | 2.030 | 1-5/8 |
| 6405- 14-08-O | 7/8 | 1-3/16-12 | 1/2-14 | 1.730 | 1-3/8 |
SAE/ORB Male X NPTF Female Adapter English Introduction
The SAE/ORB Male X NPTF Female Adapter is a precision-engineered component designed to bridge the gap between SAE/ORB and NPTF threaded systems. This adapter features a male SAE/ORB end and a female NPTF end, enabling seamless transitions between different thread types in fluid systems.
The SAE/ORB male end is designed to mate securely with SAE/ORB fittings, providing a leak-free seal that can withstand high pressures and temperatures. The precision-engineered threads ensure a snug fit, minimizing the risk of leaks and maximizing fluid transfer efficiency.
The female NPTF end, on the other hand, is compatible with NPTF-threaded components, allowing for a smooth transition to fuel systems and other piping networks that utilize this thread type. The tapered threads of the NPTF end provide a secure and reliable seal, ensuring optimal performance in high-pressure applications.
Manufactured from high-quality materials, the SAE/ORB Male X NPTF Female Adapter is durable and corrosion-resistant. It can withstand the rigors of industrial and automotive use, making it a reliable choice for various fluid system applications.
In summary, the SAE/ORB Male X NPTF Female Adapter is a versatile and reliable component that bridges the gap between SAE/ORB and NPTF threaded systems. Its precision-engineered threads and high-quality materials ensure optimal performance in a range of demanding applications.
