Part No.: 72011
Description: 72011-BSPP BANJO
Convertible code:
Material: Carbon Steel 45#
Surface Treatment: Zinc, Cr3+ Plating, Clear White
Corrossion Resistent Hour: 120h or longer
Degree: Straight
| PART NO. | THREAD E | HOSE BORE | DIMENSIONS | ||||
| DN | DASH | A | d | D | H | ||
| 72011-02-03 | G1/8x28 | 5 | 3 | 18 | 9 .9 | 24 | 16 |
| 72011-02-04 | G1/8x28 | 6 | 4 | 18 .5 | 9 .9 | 24 | 16 |
| 72011-04-03 | G1/4x19 | 5 | 3 | 19 | 13 .3 | 24 | 15 |
| 72011-04-04 | G1/4x19 | 6 | 4 | 19 .5 | 13 .3 | 24 | 15 |
| 72011-04-05 | G1/4x19 | 8 | 5 | 19 .5 | 13 .3 | 24 | 15 |
| 72011-04-06 | G1/4x19 | 10 | 6 | 19 .5 | 13 .3 | 24 | 15 |
| 72011-06-04 | G3/8x19 | 6 | 4 | 22 | 16 .7 | 29 | 20 |
| 72011-06-05 | G3/8x19 | 8 | 5 | 22 .5 | 16 .7 | 29 | 20 |
| 72011-06-06 | G3/8x19 | 10 | 6 | 22 .5 | 16 .7 | 29 | 20 |
| 72011-06-08 | G3/8x19 | 12 | 8 | 23 | 16 .7 | 29 | 20 |
| 72011-08-05 | G1/2x14 | 8 | 5 | 27 .5 | 21 | 38 | 25 |
| 72011-08-06 | G1/2x14 | 10 | 6 | 27 .5 | 21 | 38 | 25 |
| 72011-08-08 | G1/2x14 | 12 | 8 | 28 | 21 | 38 | 25 |
| 72011-08- 10 | G1/2x14 | 16 | 10 | 28 .5 | 21 | 38 | 25 |
| 72011- 10- 10 | G5/8x14 | 16 | 10 | 30 | 23 | 40 | 27 |
| 72011- 12- 10 | G3/4x14 | 16 | 10 | 31 .5 | 26 .5 | 48 | 31 |
| 72011- 12- 12 | G3/4x14 | 20 | 12 | 32 | 26 .5 | 48 | 31 |
| 72011- 16-08 | G1x11 | 12 | 8 | 40 | 33 .3 | 60 | 42 |
| 72011- 16- 12 | G1x11 | 20 | 12 | 40 | 33 .3 | 60 | 42 |
| 72011- 16- 16 | G1x11 | 25 | 16 | 41 | 33 .3 | 60 | 42 |
72011-BSPP BANJO English Introduction
The 72011-BSPP Banjo is a specialized fluid fitting designed for use in British Standard Pipe Parallel (BSPP) systems. This unique fitting offers a flexible and reliable solution for fluid transfer in a variety of industrial applications.
The Banjo design of the 72011-BSPP allows for easy and secure installation, even in tight spaces or awkward angles. Its flexible nature enables it to adapt to various configurations, ensuring a smooth and efficient flow of fluids.
Manufactured from high-quality materials, the 72011-BSPP Banjo exhibits excellent durability and resistance to corrosion. This ensures long-term performance and reliability, even in harsh industrial environments.
The BSPP thread pattern of the fitting ensures compatibility with a wide range of standard components, making it easy to integrate into existing fluid systems. The precision-machined threads provide a secure and leak-resistant seal, ensuring reliable fluid transfer.
Whether you're working with hydraulics, pneumatics, or other types of fluid systems, the 72011-BSPP Banjo is an excellent choice for a flexible and dependable fitting. Its unique design, high-quality materials, and BSPP compatibility make it a valuable addition to any industrial fluid system that requires a secure and efficient fluid transfer solution.
